Our Production Process
pvc, CPVC, UPVC, SWR, HDPE, LDPE, MDPE, AGRICULTURAL PIPES & FITTINGS
↓
[START]Order Receiving & Specification (Pipe/Fitting Type, Size, Class)
↓
Material Procurement & Storage (Resins + Additives)
↓
Material Preparation & Mixing
(Blending / Compounding)
→(Blending / Compounding)
Testing of Dry Blend / Compounds (e.g., Density, Moisture)
→Return to Compound Area
for Rework / Reject
for Rework / Reject
↓
Extrusion Line
(for Continuous Pipe)
←(for Continuous Pipe)
Material enters
Processing Lines
→Processing Lines
Injection Molding Line
(for Fittings)
(for Fittings)
↓
Die Shaping & Sizing
↓
Cooling (Vacuum
Tank & Water Spray)
Tank & Water Spray)
↓
Online Marking / Printing
(Size, Standard, etc.)
(Size, Standard, etc.)
↓
Cutting to Length (e.g., 6m, 12m)
Mold Shaping
↓
Cooling (in-mold)
↓
De-molding / Trimming
↓
Material Crushing &
Rework / Regrind
←Rework / Regrind
Testing for All Final Components
(pipes & Fittings)
→(pipes & Fittings)
Total Reject /
Disposal
Disposal
↓
Socketing / Belling
(End Forming)
(End Forming)
Visual Inspection (color, Marks, Surface) Dimensional Checks
(wall Thickness, O.D) Functional Testing (e.g., Hydrostatic Pressure, Impact)
(wall Thickness, O.D) Functional Testing (e.g., Hydrostatic Pressure, Impact)
↓
Packing & Bundling
↓
Storage & Dispatch
↓
[END]Dispatch to Customer
