Product Overview
About Garden Pipe
Godfill Garden Pipes are manufactured from high-quality flexible PVC compound in compliance with IS 12585:1988. Available in two pressure types — Type 1 (6 kg/cm²) and Type 2 (10 kg/cm²) — these hoses are ideal for garden watering, lawn maintenance and light agricultural use. Supplied in convenient 30, 50 and 100-metre coils, they offer easy handling, kink resistance and reliable performance under continuous use. Sizes range from ½" to 2" nominal bore to suit a variety of fittings and flow requirements.
Key Features
- IS 12585:1988 certified
- Two pressure types: Type 1 (6 kg/cm²) and Type 2 (10 kg/cm²)
- Available in 1/2", 5/8", 3/4", 1", 1-1/4", 1-1/2" and 2" bore sizes
- Supplied in 30 m, 50 m and 100 m coils
- Kink-resistant flexible PVC construction
- UV stabilised for outdoor use
- Compatible with standard garden fittings and connectors
- Lightweight and easy to handle
Data Sheets
Technical Specifications
Garden Pipe — Dimensions by Nominal Bore (IS 12585:1988)
| Nominal Bore (Inch) | Nominal Bore ID (mm) | Tolerance (mm) | Type 1 Wall Thickness Min. (mm) | Type 1 Wall Thickness Max. (mm) | Type 2 Wall Thickness Min. (mm) | Type 2 Wall Thickness Max. (mm) |
|---|---|---|---|---|---|---|
| 1/2" | 12.5 | ±0.75 | 1.8 | 2.2 | 2.2 | 2.6 |
| 5/8" | 16 | ±0.75 | 2 | 2.4 | 2.4 | 2.8 |
| 3/4" | 20 | ±0.75 | 2.2 | 2.6 | 2.8 | 3.2 |
| 1" | 25 | ±1.25 | 2.8 | 3.2 | 3.5 | 4 |
| 1-1/4" | 31.5 | ±1.25 | 3.2 | 3.8 | 4.2 | 4.8 |
| 1-1/2" | 40 | ±1.50 | 3.8 | 4.4 | 5 | 5.6 |
| 2" | 50 | ±1.50 | 4.5 | 5.2 | 6 | 6.8 |
Type 1: Working Pressure 6 kg/cm². Type 2: Working Pressure 10 kg/cm². Available in 30 m, 50 m and 100 m coils.
